UNIVERSAL SYMBOLS
As a guide to the operation of your tractor, various universal symbols have been utilized on the instruments and
controls. The symbols are shown below with an indication of their meaning.
Safety Alert Symbol
Engine Warning
Diesel Fuel
Fuel-Level
Engine-Rotational Speed
Hourmeter/Elapsed Operating Hours
Engine Coolant-Temperature
Diesel Preheat/Glow Plugs(Low Temperature
Start Aid)
Parking Brake/Brake Oil
Engine Oil-Pressure
Turn Signal
Electrical Power-accessories
Engine-Run
Engine-Start
Engine-Stop
Power Take-Off Clutch Control-Off (Disengaged) Position
Power Take-Off Clutch Control-On (Engaged) Position
Differential Lock
Position Control-Raised Position
Position Control-Lowered Position
Draft Control-Shallow Position
Draft Control-Deep Position
3-Point Lowering Speed Control
Remote Cylinder-Retract
Remote Cylinder-Extend
Hazard Warning Lights
Headlight-Low Beam
Headlight-High Beam
Four-Wheel Drive-On
Four-Wheel Drive-Off
Front-Wheel Drive-On
Fast
Slow
Creep
Windshield Wiper
Windshield Wiper Intermittent
Windshield Washer
Lock
Rear Window Defroster
Steering Wheel-Tilt Control
Side Window Defroster
Empty
Full
PTO 540 rpm
PTO 1000 rpm
Battery Charging Condition
