35OPERATING THE TRACTOR
PARKING
BParking
To avoid personal injury:
BEFORE DISMOUNTING TRACTOR
A ALWAYS SET PARKING BRAKE AND LOWER
ALL IMPLEMENTS TO THE GROUND.
Leaving transmission in gear with the engine
stopped will not prevent the tractor from
accidental rolling.
A STOP THE ENGINE AND REMOVE THE KEY.
1. Before getting off the tractor, disengage the PTO,
lower all implements, place all control levers in their
neutral positions, pull the parking brake lever up to
park, stop the engine and remove the key.
2. If it is necessary to park on an incline, be sure to chock
the wheels to prevent accidental rolling of the
machine.
A Do not leave your tractor in the rain. If it cannot be
avoided, cover the muffler pipe to prevent water
entering.
OPERATING TECHNIQUES
BDifferential Lock
To avoid personal injury due to loss of steering
control:
A Do not operate the tractor at high speed with
any differential lock engaged.
A Do not attempt to turn with the rear wheel or 4-
wheel differential lock engaged.
A Be sure to release the rear wheel or 4-wheel
differential locks before making a turn in field
conditions.
[2WD]
If one of the rear wheels should slip, step on the
differential lock pedal. Both wheels will turn together, then
reduce slippage.
Differential lock is maintained only while the pedal is
depressed.
A When using the differential lock, always slow the
engine down.
A To prevent damage to power train, do not engage
differential lock when one wheel is spinning and the
other is completely stopped.
A If the differential lock cannot be released, step lightly
on the brake pedals alternately.
(1) Parking brake lever
(2) Release button
(A) "PULL"
(1) Differential lock pedal
(Rear wheel)
(A) Press to "ENGAGE"
(B) Release to DISENGAGE"
To Next Page
