1SPECIFICATIONS
SPECIFICATIONS
SPECIFICATION TABLE
Model
M96SDTM
Standard With 80 in. wide axle
Engine
Model V3800-DI-TE3
Type Direct Injection, liquid cooled 4 cylinder diesel
Number of cylinders 4
Total displacement cm (cu.in.) 3769 (230)
Bore and stroke mm (in.) 100 x 120 (3.9 x 4.7)
Rated revolution rpm 2600
Low idling revolution rpm 800 to 850
Net power *1 kW (HP) 70.9 (95)
PTO power *1 (factory observed) kW (HP) 62.7 (84)
Maximum torque
N-m (ft-lbs) /
rpm
314.8 (232.2) / 1400 to 1600
Battery capacity 12V, RC: 160 min, CCA 900A
Fuel tank capacity L (U.S.gals.) 175 (46.2)
Engine oil capacity L (U.S.qts.) 10.7 (11.3)
Coolant capacity L (U.S.qts.) 9.6 (10.1)
Dimensions
Overall length mm (in.) 4275 (168.3)
Overall width
(minimum tread)
mm (in.) 2030 (79.9) 2270 (89.4)
Overall height (with ROPS) mm (in.) 2835 (111.6)
Wheel base mm (in.) 2420 (95.3)
Tread
Front mm (in.) 1565 (61.6), 1665 (65.6)
1830 (72), 1925 (75.8),
2025 (79.7)
Rear mm (in.) 1545 (60.8), 1645 (64.8)
1865 (73.4), 1960 (77.2),
2060 (81.1)
Minimum ground clearance mm (in.) 655 (25.8) (Drive Case)
Weight (with ROPS) kg (lbs.) 3620 (7981) 3700 (8157)
Traveling
system
Standard
tire size
Front tires 13.6-38
Rear tires 13.6-38
Clutch Hydraulic wet disks
Steering Hydraulic Power Steering
Braking system Hydraulic wet disks
Differential Bevel gears with differential lock (Front, Rear)
M96SDTM
