OPERATING THE TRACTOR36
[4WD]
1. If the front and/or rear wheels should slip while driving
straight in field conditions, step on the 4-wheel
differential lock pedal. The four wheels will turn
together, then reduce slippage.
2. If the front and/or rear wheels slip while in a turn in field
conditions, step on the front wheel differential lock
pedal only. The front wheels alone will rotate together
for easy turning.
A When using the differential lock, always slow the
engine down.
A To prevent damage to power train, do not engage
differential lock when one wheel is spinning and the
other is completely stopped.
A To prevent damage to power train, do not attempt to
turn the tractor when 4-wheel differential lock pedal is
pressed down.
A If the differential lock cannot be released:
A 4-wheel differential lock pedal:
--- Step lightly on the brake pedals alternately.
A Front wheel differential lock pedal:
--- Turn the steering wheel alternately.
BOperating the Tractor on a Road
To avoid personal injury:
A To help assure straight line stops when driving
at transport speeds, lock the brake pedals
together. Uneven braking at road speeds could
cause the tractor to roll-over.
A When traveling on road with 3-point hitch
mounted implement attached, be sure to have
sufficient front weight on the tractor to
maintain steering ability.
Be sure SMV emblem and warning lamps are clean and
visible. If towed or rear-mounted equipment obstructs
these safety devices, install SMV emblem and warning
lamps on equipment.
Consult your local KUBOTA Dealer for further details.
(1) 4-wheel differential lock
pedal (Rear and Front wheel)
(2) Front wheel differential
lock pedal (Front wheel only)
(A) Press to "ENGAGE"
(B) Release to "DISENGAGE"
(1) SMV emblem
(2) Bracket
To Next Page
