TIRES, WHEELS AND BALLAST56
BRear Wheels
Rear tread width can be adjusted as shown with the
standard equipped tires.
To change the tread width
1. Remove the wheel rim and / or disk mounting bolts.
2. Change the position of the rim and / or disk (right and
left) to the desired position, and tighten the bolts.
A Always attach wheels as shown in the drawing.
A If not attached as illustrated, transmission parts may
be damaged.
A When re-fitting or adjusting a wheel, tighten the bolts
to the following torques then recheck after driving the
tractor 200m (200 yards) and thereafter according to
service interval.
(See "MAINTENANCE" section.)
(1) 343 to 401 N-m (35.0 to 41.0 kgf-m) (254 to 297 ft-lbs)
(2) [Steel disc] 244 N-m (24.9 kgf-m) (180 ft-lbs)
[Cast iron disc]
260 to 304 N-m (26.5 to 31.0 kgf-m) (192 to 224 ft-lbs)
