Kyocera FS-C5350DN Service Manual

2K8
2-1-16
Figure 2-1-17 Transfer/separation section block diagram
Engine PWB
High voltage PWB
Left ID sensor
Right
ID sensor
Secondary
transfer rolle
r
Primary
transfer
roller M
Primary
transfer
roller C
Primary
transfer
roller Y
Primary
transfer
roller K
Transfer belt
Cleaning
roller
T2RREMN
Secondary transfer bias output
Primary transfer bias output K
Primary transfer bias output Y
Primary transfer
bias output C
Primary transfer
bias output M
Cleaning bias output
YC16-7
VOSL VOPL
LEDREFL
VOSR VOPR
LEDREFR
YC5-5 YC5-4 YC5-2 YC6-5 YC6-4 YC6-2
CN1-21
CLCNT
YC16-20
CN1-8
T1MCNT
YC16-21
CN1-7
T1CCNT
YC16-22
CN1-6
T1YCNT
YC16-23
CN1-5
T1KCNT
YC16-24
CN1-4
T2CNT
YC16-25
CN1-3

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
