Kyocera FS-C5350DN Service Manual

2K8
1-3-18
Service items Description
No. Items Description
 Maintenance
Log
NOTE:
It is not logged if
100 or more
counts are not
added to the
count at the last
occurrence of
replacement.
# Count. Item
Remembers 1 to 8 of
occurrence of replace-
ment. If the occurrence of
the previous replacement
of toner container is less
than 8, all of the occur-
rences of replacement
are logged.
The total page count at the
time of the replacement of
the toner container.
This is virtually logged as
the occurrence of the
“Toner Empty” or “Install
MK” condition since the
replacement of the toner
container is not precisely
detectable.
Code of maintenance replacing
item (1 byte, 2 categories)
First byte (Replacing item)
01: Toner container
Second byte (Type of replacing
item)
00: Black
01: Cyan
02: Magenta
03: Yellow
First byte (Replacing item)
02: Maintenance kit
Second byte (Type of replacing
item)
01: Fixed (MK-580)
 Unknown Toner
Log
NOTE:
It is not logged if
100 or more
counts are not
added to the
count at the last
error.
# Count. Item
Remembers 1 to 5 of
occurrence of unknown
toner detection.
If the occurrence of the
previous unknown toner
detection is less than 5,
all of the unknown toner
detection are logged.
The total page count at the
time of the “Toner Empty”
error with using an
unknown toner container.
Unknown toner log code (1
byte, 2 categories)
First byte
01: Fixed (Toner container)
Second byte
00: Black
00: Cyan
00: Magenta
00: Yellow
 Counter Log
Comprised of
three log
counters includ-
ing paper jams,
self diagnostics
errors, and
replacement of
the toner con-
tainer.
NOTE:
It is not logged if
100 or more
counts are not
added to the
count at the last
error.
(f) Jam (g) Self diagnostic error (h) Maintenance item replacing
Indicates the log counter
of paper jams depending
on location.
Refer to Paper Jam Log.
All instances including
those are not occurred
are displayed.
Indicates the log counter of
self diagnostics errors
depending on cause.
(See page 1-4-3)
Example
C6000: 4
Self diagnostics error
6000 has happened four
times.
Indicates the log counter
depending on the maintenance
item for maintenance.
T: Toner container
00: Black
00: Cyan
00: Magenta
00: Yellow
M: Maintenance kit
00: (Fixed)
Example
T00: 1
The (black) toner container has
been replaced once.
This is virtually logged as the
occurrence of the” Toner Empty”
or “Install MK” condition.

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
