Kyocera FS-C5350DN Service Manual

2K8-1
1-4-20
F030 Main PWB general failure Defective main
PWB.
Turn the power switch off/on to restart the
printer. If the error is not resolved, replace
main PWB (See page 1-5-28).
F040 Main PWB - Engine PWB communica-
tion error
Faulty connection
of the connector
between the main
PWB and engine
PWB.
Check the installation of the main PWB and
engine PWB and reinstall them if necessary
(See page 1-5-28 and 1-5-29).
Defective main
PWB.
Turn the power switch off/on to restart the
printer. If the error is not resolved, replace
main PWB (See page 1-5-28).
Defective engine
PWB.
Replace engine PWB (See page 1-5-29).
F050 Engine PWB ROM checksum error Some error may
have occurred
when downloading
the firmware of the
engine PWB.
Download the firmware of the engine PWB
again using the memory card (See page 1-
6-4).
Defective engine
PWB.
Turn the power switch off/on to restart the
printer. If the error is not resolved, replace
engine PWB (See page 1-5-29).
F186 Main PWB video data control error Defective main
PWB.
Turn the power switch off/on to restart the
printer. If the error is not resolved, replace
main PWB (See page 1-5-28).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
