2K8
1-3-8
Printing a status page for network
Description
On the status page for network, detailed network setting information is printed.
Procedure
1. Enter the service mode [>>Print Network Status Page].
2. Press the OK key. [>>Print Network Status Page?] will be displayed.
3. Press the OK key. Three sheets of network status page will be printed.
Completion
Printing a test page
Description
Four colors are printed respectively with halftones of three different levels.
Purpose
To check the activation of the developer and drum units of four colors.
Procedure
1. Enter the service mode [>>Print Test Page].
2. Press the OK key. [>>Print Test Page?] will be displayed.
3. Press the OK key. A sheet of test page will be printed.
Completion
*
1
: Since focusing in yellow is hardly readable, yellow is mixed with cyan for more readability,
resulting in green.
*
2
: Each portion of colors has three different magnitude of halftones (bands). If focus is
excessively lost, dots are not recognizable with the 16/256 band, resulting in uneven
density. It also results in vertical streaks in the 24/256 and/or 32/256 bands.
Figure 1-3-3 Test page
Service items Description
>>Print Network
Status Page
>>Print
Test Page
16/256
24/256
32/256
Black
Cyan
Magenta
Green*
1
(Yellow)
Density*
2
To Next Page
