Kyocera FS-C5350DN Service Manual

2K8
1-4-8
2102 Developing motor MCY error
The ready signal cannot be detected
within 5 seconds after the developing
motor MCY turns on.
Defective harness
between develop-
ing motor MCY and
engine PWB
(YC27), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective drive
transmission
system of the
developing motor
MCY.
Check if the gears rotate smoothly. If not,
grease the bushings and gears. Check for
broken gears and replace if any.
Defective develop-
ing motor MCY.
Replace the developing motor MCY.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
2250 Main charger cleaning motor error
When the main charger cleaning motor
is driven, the main charger cleaning
motor over-current detection signal is
detected continuously for 50 times (5 s)
at 100 ms intervals.
Defective harness
between main
charger cleaning
motor and engine
PWB (YC36), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective drive
transmission sys-
tem of the main
charger cleaning
motor.
Check if the rollers and gears rotate
smoothly. If not, grease the bushings and
gears. Check for broken gears and replace if
any.
Defective main
charger cleaning
motor.
Replace the main charger cleaning motor.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
2500 Paper feed motor error
The paper feed motor ready input is not
given for 5 seconds during the main
motor is ON.
Defective harness
between paper
feed motor and
engine PWB
(YC3), or improper
connector inser-
tion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective drive
transmission sys-
tem of the paper
feed motor.
Check if the rollers and gears rotate
smoothly. If not, grease the bushings and
gears. Check for broken gears and replace if
any.
Defective paper
feed motor.
Replace the paper feed motor.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
