Kyocera FS-C5350DN Service Manual

2K8
1-4-28
1-4-4 Electric problems
Problem Causes Check procedures/corrective measures
(1)The machine does
not operate when the
power switch is
turned on.
The power cord is not
plugged in properly.
Check the contact between the power plug and the outlet.
No electricity at the power
outlet.
Measure the input voltage.
Broken power cord. Check for continuity. If none, replace the cord.
Defective power switch. Check for continuity across the contacts. If none, replace the
power switch.
Defective power source
PWB.
Replace the power source PWB (See page 1-5-26).
(2)Drum motor M/C/
Y/K, duplex motor
and fuser motor do
not operate.
Defective harness or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
Drum motor M/C/Y/K - Engine PWB (YC18)
Duplex motor - Engine PWB (YC17)
Fuser motor - Engine PWB (YC39)
Broken the gear. Check visually and replace the gear if necessary.
Defective motor. Replace the motor.
Defective engine PWB. Replace the engine PWB (See page 1-5-29).
(3)Power source fan
motor, ozone fan
motor, developing fan
motor1/2 and fuser
fan motor 1/2 do not
operate.
Broken the fan motor coil. Check for continuity across the coil. If none, replace the fan
motor.
Defective harness or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
Power source fan motor - Engine PWB (YC8)
Ozone fan motor - Engine PWB (YC11)
Developing fan motor 1 - Engine PWB (YC10)
Developing fan motor 2 - Engine PWB (YC41)
Fuser fan motor 1 - Paper exit PWB (YC2)
Fuser fan motor 2 - Engine PWB (YC44)
Defective engine PWB. Replace the engine PWB (See page 1-5-29).
(4)Paper feed clutch,
registration clutch,
developing clutch K,
duplex clutch and
intermediate clutch
do not operate.
Broken clutch coil. Check for continuity across the coil. If none, replace the clutch.
Defective harness or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
Paper feed clutch - Engine PWB (YC26)
Registration clutch - Engine PWB (YC26)
Developing clutch K - Engine PWB (YC26)
Duplex clutch - Engine PWB (YC3)
Intermediate clutch - Engine PWB (YC3)
Defective engine PWB. Replace the engine PWB (See page 1-5-29).
(5)MP paper feed
solenoid, ID solenoid,
duplex solenoid do
not operate.
Broken solenoid coil. Check for continuity across the coil. If none, replace the solenoid.
Defective harness or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
MP paper feed solenoid - Engine PWB (YC40)
ID solenoid - Engine PWB (YC43)
Duplex solenoid - paper exit PWB (YC3)
Defective engine PWB. Replace the engine PWB (See page 1-5-29).
Defective paper exit PWB. Replace the paper exit PWB.

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
