Kyocera FS-C5350DN Service Manual

2K8
1-4-6
1600
1620
1640
PF warm air heater (upper blower) low
temperature error*
(Option paper feeder)
An external temperature higher than
+5
°C/+41°F is not detected when one
minute elapses after PF warm air heater
2 is turned on.
*
: Multi purpose feeder only
1600: Paper feeder 1
1620: Paper feeder 2
1640: Paper feeder 3
Defective harness
between PF warm
air heater 2 and PF
warm air heater
driver PWB (YC2),
or improper con-
nector insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness. (Refer to the
service manual for the paper feeder).
Defective harness
between PF warm
air heater driver
PWB (YC3) and
PF main PWB
(YC13), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness. (Refer to the
service manual for the paper feeder).
Defective harness
between PF ther-
mistor 2 and PF
main PWB (YC12),
or improper con-
nector insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness. (Refer to the
service manual for the paper feeder).
PF thermistor 2
installed incor-
rectly.
Check the installation of the PF thermistor 2
and remedy if necessary (Refer to the ser-
vice manual for the paper feeder).
Defective PF ther-
mistor 2.
Replace the PF thermistor 2 (Refer to the
service manual for the paper feeder).
PF thermal cutout
2 triggered.
Replace the PF thermal cutout 2 (Refer to
the service manual for the paper feeder).
Broken PF warm
air heater 2.
Replace the PF warm air heater 2 (Refer to
the service manual for the paper feeder).
Defective PF warm
air heater driver
PWB.
Replace the PF warm air driver PWB (Refer
to the service manual for the paper feeder).
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
