Kyocera FS-C5350DN Service Manual

2K8
1-3-2
(2) Service mode
Service items Description
Printing a status page for service purpose
Description
Prints a status page for service purpose. The status page includes various printing settings
and service cumulative.
Purpose
To acquire the current printing environmental parameters and cumulative information.
Procedure
1. Enter the service mode [>>Print Status Page].
2. Press the OK key. [Print Status Page?] will be displayed.
3. Press the OK key. Two pages will be printed.
Completion
Service status page (1)
Figure 1-3-1
>>Print
Status Page
Firmware Version 2K8_3000.000.040
1
Memory Status
Standard Size
Option Slot
Total Size
Controller Information
2009.05.27 [XXXXXXXX] [XXXXXXXX] [XXXXXXXX] [XXXXXXXX]
[XXXXXXXXXXXXXXXX]
500.0 kB
500.0 kB
1000.0 kB
Time
Local Time Zone
Time Server
+01:00 Amsterdam
10. 183. 53. 13
FRPO Status
Default Pattern Switch
Default Font Name
B8
V3
00
Courier
e-MPS error control Y6 0
Service Status Page
Printer




Digital Dot Coverage
Average (%)
K: 1.00
C: 2.22
M: 3.33
Y: 4.44
Last Page K/C/M/Y (%) 1.00 / 2.22 / 3.33 / 4.44
/ Usage Page (A4/Letter Conversion)
/ 11111111. 00
/ 2222222. 22
/ 3333333. 33
/ 4444444. 44

Installed Options
Paper Feeder2
Paper Feeder3
Paper Feeder4
Paper Feeder5
Memory Card
Hard Disk
Installed
Installed (Multi purpose)
Not Installed
Not Installed
Installed
Installed













Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
