Kyocera FS-C5350DN Service Manual

2K8
1-4-3
(2) Self diagnostic codes
Code Contents
Remarks
Causes Check procedures/corrective measures
0100 Backup memory read/write error Defective main
PWB.
Replace the main PWB (See page 1-5-28).
0110 Backup memory data error Defective main
PWB.
Replace the main PWB (See page 1-5-28).
0120 MAC address data error
For data in which the MAC address is
invalid.
Defective main
PWB.
Replace the main PWB (See page 1-5-28).
0150 Engine PWB (EEPROM) error
Data read from EEPROM is judged
abnormal.
Improper installa-
tion EEPROM.
Replace the engine PWB (See page 1-5-
29).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
0170
Billing counting error
Defective main
PWB.
Replace the main PWB (See page 1-5-28).
0420 Paper feeder communication error
Communication error between engine
PWB and optional paper feeder.
Improper installa-
tion paper feeder.
Follow installation instruction carefully again.
Defective harness
between PF main
PWB (YC3, YC5)
and paper feeder
interface connec-
tor, or improper
connector inser-
tion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness. (Refer to the
service manual for the paper feeder).
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
Defective harness
between engine
PWB (YC33) and
paper feeder inter-
face connector, or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
0600 Expanded memory (DIMM) installing
error
The expansion memory modules (DIMM)
are not correctly mounted.
Improper installa-
tion expanded
memory (DIMM).
Check the installation of the expanded mem-
ory (DIMM) and remedy if necessary.
0610 Expanded memory (DIMM) error
The expansion memory modules (DIMM)
mounted on the main PWB does not
operate correctly.
Defective
expanded memory
(DIMM).
Replace the expanded memory (DIMM)
(See page 1-2-5).
Defective main
PWB.
Replace the main PWB (See page 1-5-28).

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
