Kyocera FS-C5350DN Service Manual

2K8
1-4-14
6020 Abnormally high temperature fuser
heater lamp
The fuser thermistor detects a tempera-
ture higher than 240°C/464°F.
By the activation of the high temperature
error detection circuit (230
°C/446°F or
more) of fuser thermistor, the illumination
of fuser heater lamp was forcibly turned
off and 10 seconds has elapsed.
Shorted fuser ther-
mistor.
Replace the fuser unit (See page 1-5-25).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
6030 Broken fuser thermistor wire
Input from fuser thermistor is 3 or less
(A/D value) continuously for 1.1 second
(11 ms × 100 times).
Defective harness
between fuser ther-
mistor and paper
exit PWB (YC4), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective harness
between paper exit
PWB (YC1) and
engine PWB
(YC20), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Broken fuser ther-
mistor wire.
Replace the fuser unit (See page 1-5-25).
Fuser thermistor
installed incor-
rectly.
Replace the fuser unit (See page 1-5-25).
Fuser thermal cut-
out triggered.
Replace the fuser unit (See page 1-5-25).
Fuser heater lamp
installed incor-
rectly.
Replace the fuser unit (See page 1-5-25).
Broken fuser
heater lamp wire.
Replace the fuser unit (See page 1-5-25).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
6400 Zero cross signal error
The zero cross signal does not reach the
engine PWB for specified time.
Defective harness
between power
source PWB
(YC103) and
engine PWB
(YC19), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective power
source PWB.
Replace the power source PWB (See page
1-5-26).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
