Kyocera FS-C5350DN Service Manual

2K8
1-4-12
5301 Broken eraser lamp K wire
When the eraser lamp K is driven, the
eraser lamp K over-current detection sig-
nal is detected continuously for 10 times
(1 s) at 100 ms intervals.
Defective harness
between drum unit
K and drum relay
PWB (YC2/YC3),
or improper con-
nector insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective harness
between drum
relay PWB (YC1)
and engine PWB
(YC34), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective eraser
lamp K.
Replace the drum unit K. (See page 1-5-14).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
5302 Broken eraser lamp C wire
When the eraser lamp C is driven, the
eraser lamp C over-current detection sig-
nal is detected continuously for 10 times
(1 s) at 100 ms intervals.
Defective harness
between drum unit
C and drum relay
PWB (YC8/YC9),
or improper con-
nector insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective harness
between drum
relay PWB (YC1)
and engine PWB
(YC34), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective eraser
lamp C.
Replace the drum unit C (See page 1-5-14).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
5303 Broken eraser lamp M wire
When the eraser lamp M is driven, the
eraser lamp M over-current detection
signal is detected continuously for 10
times (1 s) at 100 ms intervals.
Defective harness
between drum unit
M and drum relay
PWB (YC11/
YC12), or improper
connector inser-
tion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective harness
between drum
relay PWB (YC1)
and engine PWB
(YC34), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective eraser
lamp M.
Replace the drum unit M (See page 1-5-14).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
