Kyocera FS-C5350DN Service Manual

2K8
1-4-15
7001 Toner motor K error
When the toner motor K is driven, the
toner motor K over-current detection sig-
nal is detected continuously for 50 times
(5 s) at 100 ms intervals.
Defective harness
between toner
motor K and
engine PWB
(YC22), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective drive
transmission
system of the toner
motor K.
Check if the gears rotate smoothly. If not,
grease the bushings and gears. Check for
broken gears and replace if any.
Defective toner
motor K.
Replace the toner motor K.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
7002 Toner motor C error
When the toner motor C is driven, the
toner motor C over-current detection sig-
nal is detected continuously for 50 times
(5 s) at 100 ms intervals.
Defective harness
between toner
motor C and
engine PWB
(YC24), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective drive
transmission
system of the toner
motor C.
Check if the gears rotate smoothly. If not,
grease the bushings and gears. Check for
broken gears and replace if any.
Defective toner
motor C.
Replace the toner motor C.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
7003 Toner motor M error
When the toner motor M is driven, the
toner motor M over-current detection sig-
nal is detected continuously for 50 times
(5 s) at 100 ms intervals.
Defective harness
between toner
motor M and
engine PWB
(YC25), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective drive
transmission
system of the toner
motor M.
Check if the gears rotate smoothly. If not,
grease the bushings and gears. Check for
broken gears and replace if any.
Defective toner
motor M.
Replace the toner motor M.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
