Kyocera TASKalfa 2201 User Manual

7-32
System Menu and KYOCERA Client Tool > Default Settings on the PC (KYOCERA Client Tool)
Print Box Settings
Configure the Print Box settings on [Print Box Destination] of the [Device] tab.
A maximum of 30 Print Boxes can be created.
IMPORTANT
• When sending a print job from the Client PC via a network, Box, Destination folder and PIN Code set by
KYOCERA Client Tool need to be assigned to each Client PC.
• To reflect settings in the machine, the [Reset] key on the operation panel of the machine needs to be
pressed.
NOTE
Scan, Print Box, and device monitoring will be disabled while the [Print Box] window is open.
Item Description
Box number Select the box number (1 to 30) to be registered. When a box number is selected, the settings
registered in that number appear in the right-hand screen.
Summary Shows a list of the settings of the selected box.
Name Set a name for the Print Box. Up to 16 characters can be entered. This name is displayed when you
select a Print Box on the machine operation panel.
NOTE
If a document is stored in the box for which no Box name is set, printing from the box is not available.
PIN Code With a PIN code assigned to the Print Box, executing the print jobs in the Print Box from the machine
requires entry of the PIN code, thereby restricting user access to the print jobs. Since third parties who
do not know the PIN cannot print, security is enhanced. (Entering a password is not mandatory.)
Select the checkbox to assign a PIN code to and enter a 4-digit numeric value.
Connection Settings Select the interface used to connect with the machine.
When connecting the machine to the PC on the network, configure the host name or IP address of the
PC in use.
*1
Refer to When Connecting the Machine to the PC on the Network on page 2-38.
*1 The optional Network Interface Kit is required.
Destination folder Specify the path for the folder to be used as the Print Box. To select the folder, click [Browse] to open
"Browse for Folder".
IMPORTANT
No folder can be created in a machine other than the PC in use.
Reset Reset the Print Box to default values.
Save Save your settings.

Kyocera TASKalfa 2201 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.7 s
Print speed (black, normal quality, A3)	10 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Scan to	E-mail, Image
Scan drivers	TWAIN
Grayscale levels	256
Image formats supported	BMP, JPG, TIF
Document formats supported	PDF
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax coding methods	MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	4 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Processor family	ARM
Card reader integrated	No
Sound pressure level (printing)	62 dB
Sound pressure level (quiet mode)	40 dB
Paper input type	Cassette, Paper tray
Total input capacity	400 sheets
Total output capacity	250 sheets
Maximum input capacity	1300 sheets
Multi-Purpose tray input capacity	100 sheets
Paper tray media types	Plain paper
Paper tray media weight	64 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	45 - 160 g/m²
Market positioning	Business
Standard interfaces	USB 2.0
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	76 W
Power consumption (PowerSave)	1.54 W
Power consumption (average operating)	415 W
Certification	TÜV/GS, CE

Weight and Dimensions

Depth	527 mm
Width	565 mm
Height	485 mm
