COMPONENT MAINTENANCE MANUAL
AVIATION RECORDERS
Model FA5000
Initial Issue Page 701
Sep. 30/11
Assembly
23–70–40
Use or disclosure of information on this sheet is subject to
the restrictions on the cover page of this document.
ASSEMBLY
1. GENERAL
This section contains procedures describing the assembly of the Model FA5000 as well
as storage instructions after assembly. There is no special testing necessary during as-
sembly. However, once assembly is completed, the operational test procedure provided
in the Testing and Troubleshooting Section 100 should be performed to verify proper op-
eration of the Recorder.
2. REQUIRED MATERIALS
Special equipment required for testing and assembly of the recorder can be found in
Table 901 of the Special Tools, Fixtures, and Equipment Section 900 of this CMM.
Table 701 provides a list of the common assembly materials used with the FA5000.
Table 701. Required Assembly Materials
Item Manufacturing and Specification Use
1. Adhesive Loctite, Grade E, Purple No. 222
Lock/sealant manufactured by Loctite Corp.,
705 N. Mountain Rd.,
Newington, CT 06111 [V05972]
Retain screws
2. Torque Wrench L-3 Communications p/n: 9300-921, or
equivalent
Beacon Bracket mount-
ing screws (75 in/lbs.);
CSMU (31 in/lbs); Rear
Cover screws, AI PWA
screws (9-10 in/lbs.); J1
Connector, CSMU Con-
nector and CSMU cover
screws (5-6 in/lbs.); J2
cover and Front Shiel-
ded cover screws (2−3
in/lbs)
