L3 FA5000 Component Maintenance Manual With Illustrated Parts List

COMPONENT MAINTENANCE MANUAL
AVIATION RECORDERS
Model FA5000
Initial Issue Page 807
Sep. 30/11
Fits and Clearances
23–70–40
Use or disclosure of information on this sheet is subject to
the restrictions on the cover page of this document.
[96.5]
[21.3]
[6.1]
[137.2]
[303.3]
2x
2x
3.6+/−.2
3.80
.84
.24
5.40
6X 0.22
[96.5]
2x
3.80
[251.3]
9.89
[91.4+/−5.0]
11.94
Figure 801. Sheet 1 of 2
Outline & Dimension Drawing
Model FA5000 Cockpit Voice Recorder/Flight Data Recorder
Rev. 04 Page 807
Mar. 21/14
