COMPONENT MAINTENANCE MANUAL
AVIATION RECORDERS
Model FA5000
Rev. 04 Page 122
Feb. 27/14
Testing & Fault Isolation
23–70−40
Use or disclosure of information on this sheet is subject to
the restrictions on the cover page of this document.
08:03:52 PASSED Rotor Speed 6000 Hz (Expected 4 patterns > 5880.0 Hz <
6120.0 Hz) Results = 5998.0 Hz, 6026.4 Hz, 6026.4 Hz, 6026.4 Hz
08:04:03 PASSED Rotor Speed 7 Hz (Expected 4 patterns > 6.9 Hz < 7.1 Hz)
Results = 7.0 Hz, 7.0 Hz, 7.0 Hz, 7.0 Hz
(7) Channel Balance
Record simulated 1000 Hz ½ reference level data for each channel 1,2,3 and 4 and
verify amplitude all within 3 dB.
Record simulated 1000 Hz 1/10 reference level data for each channel 1,2,3 and 4
and verify amplitude all within 3 dB.
Example report message(s):
08:04:52 PASSED Channel Bal 1000 Hz 0.5 ref (All within 3 dB except HQC)
Results = HQ1 5.2 /HQ2 5.3 /HQ3 5.1 /HQC 5.1 /SQV1 5.0 /SQV2 5.4 /SQV3
5.4 /SQC −56.6 dBV
08:05:40 PASSED Channel Bal 1000 Hz 0.1 ref (All within 3 dB except HQC)
Results = HQ1 −8.3 /HQ2 −8.2 /HQ3 −8.4 /HQC −9.4 /SQV1 −8.0 /SQV2 −8.1
/SQV3 −8.1 /SQC −293.8 dBV
(8) Frequency Response
Record simulated 150 Hz ½ reference data for each channel 1,2,3 and 4.
Record simulated 1000 Hz ½ reference data for each channel 1,2,3 and 4.
Record simulated 3500 Hz ½ reference data for each channel 1,2,3 and 4.
Record simulated 5000 Hz ½ reference data for channel 4.
Record simulated 6000 Hz ½ reference data for channel 4.
Verify amplitude all within 6 dB.
Example report message(s):
08:06:28 Frequency Resp 150 Hz 0.5 ref Results = HQ1 3.6 /HQ2 3.8 /HQ3 3.5
/HQC 1.4 /SQV1 3.9 /SQV2 3.9 /SQV3 3.9 /SQC 3.9 dBV
08:07:15 Frequency Resp 1000 Hz 0.5 ref Results = HQ1 5.2 /HQ2 5.3 /HQ3
5.1 /HQC 5.1 /SQV1 5.4 /SQV2 5.4 /SQV3 5.4 /SQC 5.4 dBV
08:08:02 Frequency Resp 3500 Hz 0.5 ref Results = HQ1 3.3 /HQ2 2.9 /HQ3
2.5 /HQC 5.1 /SQV1 3.7 /SQV2 3.7 /SQV3 3.8 /SQC 3.5 dBV
