Lenze i550 Series Mounting Instructions

3-phase mains connecon 400 V
Rated data
Inverter I55AP137F..7 I55AP155F..7 I55AP175F..7 I55AP211F..7 I55AP215F..7 I55AP222F..7
Rated power kW 0.37 0.55 0.75 1.1 1.5 2.2
Rated power hp 0.5 0.75 1 1.5 2 3
Mains voltage range 3/PE AC 340 V...528 V, 45 Hz...65 Hz
Output voltage 3 AC 0-400/480 V
Rated mains current
without mains choke A 1.8 2.5 3.3 4.4 5.4 7.8
Apparent output power kVA 0.9 1.2 1.6 2.2 2.6 3.6
Rated output current
2 kHz A 1.3 1.8 2.4 3.2 3.9 5.6
4 kHz A 1.3 1.8 2.4 3.2 3.9 5.6
8 kHz A 1.3 1.8 2.4 3.2 3.9 5.6
12 kHz A 1 1.4 1.9 2.9 3.5 5
16 kHz A 0.9 1.2 1.4 2.1 2.6 3.7
Power loss
2 kHz W 19 24 30 38 45 62
4 kHz W 20 25 32 40 48 66
8 kHz W 24 31 40 51 61 85
12 kHz W 23 30 38 54 65 91
16 kHz W 22 28 35 49 58 81
when the controller is
inhibited
W 6 6 6 6 6 6
Cyclic mains switching 3 mes per minute
Max. shielded motor cable
length
without EMC category m 50 50 50 50 50 50
Category C1 (2 kHz, 4 kHz, 8
kHz)
m 3 3 3 3 3 3
Category C2 (2 kHz, 4 kHz, 8
kHz)
m 20 20 20 20 20 20
Category C3 (2 kHz, 4 kHz, 8
kHz)
m 35 35 35 35 35 35
Weight kg 1.8 1.8 1.8 2.7 2.7 2.7
Weight lb 4 4 4 6 6 6
Technical data
3-phase mains connecon 400 V
Rated data
108

Lenze i550 Series Specifications

General

Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Overload Capacity	150% for 60 seconds
Control Type	Vector control
Communication Interfaces	CANopen, Modbus, Ethernet, PROFIBUS, PROFINET
Safety	STO (Safe Torque Off)
Frequency Range	0 Hz
Cooling Method	Air cooling
Storage Temperature Range	-25°C to +70°C
Input Voltage Range	3-phase 380...480 V AC -15%/+10%
