Lenze i550 Series Mounting Instructions

Modbus TCP
Status displays at the RJ45 sockets
The LEDs at the RJ45 sockets indicate the connecon status to the network:
LED "Link" (green) Status/meaning
o No connecon to the network.
on
A physical connecon to the network is available.
LED "Acvity" (yellow) Status/meaning
o No data transfer.
on or ickers
Data is exchanged via the network.
Typical topologies
Line Tree
M
R
Sn
S2S1
M
SWn
SW2
SW1
M Master SW Switch
S Slave
Bus-related informaon
Name Modbus TCP
Communicaon medium Ethernet 10 Mbps, 100 Mbps, half
duplex, full duplex
Use Connecon of the inverter to a
Modbus TCP network
Connecon system RJ45
Status display 2 LEDs
Connecon designaon Port 1: X276
Port 2: X277
Basic network sengs
The rotary encoder switch allows you to set the last byte of the IP address.
x16 x1
Seng Value of last byte Resulng IP address
0x00 Value from parameter Value from parameter
0x01 ... 0xFE Switch posion 192.168.124.<switch posion>
0xFF Default seng 192.168.124.16
Electrical installaon
Networks
Modbus TCP
93

Lenze i550 Series Specifications

General

Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Overload Capacity	150% for 60 seconds
Control Type	Vector control
Communication Interfaces	CANopen, Modbus, Ethernet, PROFIBUS, PROFINET
Safety	STO (Safe Torque Off)
Frequency Range	0 Hz
Cooling Method	Air cooling
Storage Temperature Range	-25°C to +70°C
Input Voltage Range	3-phase 380...480 V AC -15%/+10%
