Lenze i550 Series Mounting Instructions

Features
0.37 kW ... 11 kW
X16
X2xx
X109
X9
X20
X1
X3
X100
X105
Control terminals
Network status LEDs
Memory module
Inverter status LEDs
Netw rk, ptiono o
PTC input
Relay output
Diagnostic interface
Diagnos odultic m e
Shield connection
Safety module
Mains connection
Motor connection
DIP switch
Micro-USB
Standard I/O
Cable glands with shield connection
Keypad or WLAN module
Brake resistor
connection
DC bus
Ethernet-based networks
Rotary encoder
switch
Control cable
Slot
Meaning of the status LEDs for the various networks
Network LED le LED right
CANopen CAN-RUN CAN-ERR
Modbus COMM ERR
EtherCAT RUN ERR
Ethernet/IP NS MS
PROFINET BUS-RDY BUS-ERR
Modbus/TCP NS MS
Licence informaon
Lenze Soware may contain soware elements that are licensed as free soware or open
source.The licensing terms and condions of the open source soware components used in this
product can be found on the Lenze website. See licensing terms
Licence informaon
PROFINET rmware is oponal.
The PROFINET rmware uses the following open source soware packages under a modied GPL licence:
eCos Operang System. These components are used at the operang system level of the rmware. The
protocol stack does not use source code under a GPL licence. View licence.
Product informaon
Licence informaon
67

Lenze i550 Series Specifications

General

Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Overload Capacity	150% for 60 seconds
Control Type	Vector control
Communication Interfaces	CANopen, Modbus, Ethernet, PROFIBUS, PROFINET
Safety	STO (Safe Torque Off)
Frequency Range	0 Hz
Cooling Method	Air cooling
Storage Temperature Range	-25°C to +70°C
Input Voltage Range	3-phase 380...480 V AC -15%/+10%
