Linksys LAPAC1750PRO User Manual

98
Section 3: Configuring the Access Point
LAPAC1750PRO Access Point Software User Manual
Local Users
You can configure a captive portal instance to accommodate both guest
users and authorized users. Guest users do not have assigned user names and
passwords.
Authorized users provide a valid user name and password that must first be
validated against a local database or RADIUS server. Authorized users are
typically assigned to a CP instance that is associated with a different VAP than
guest users.
Use the Local Users page to configure up to 128 authorized users in the local
database.
Click the Configuration > Captive Portal > Local Users tab to access the page,
which the following figure shows.
Figure 55: CP Local Users
The following table describes the fields on the CP Local Users page that you
use to create a CP local user.
Table 62: Creating Captive Portal Local Users
Field Description
Captive Portal Users To create a new user, select Create.
User Name Specify a name for the local user.
After you create a user or select an existing user from the Captive Portal Users
menu, additional fields appear on the screen.
The following table describes the fields on the CP Local Users page that you
use to configure settings for an existing CP local user.
Table 63: Creating Captive Portal Local Users
Field Description
Captive Portal Users Select the name of the user with the settings to
configure.
User Password Enter the user’s password, from 8 to 64
alphanumeric and special characters. A user enter
must enter the password to log into the network
through the captive portal.
Away Time The amount of time a user remains in the CP
authenticated client list after it disassociates from
the AP. If the time specified in this field expires
before the client attempts to reauthenticate, its
entry is removed from the authenticated client
list. The range is from 0 to 1440 minutes. The
default value is 0.
Note: An away timeout value is also configured
for a captive portal instance. See the Instance
Configuration page. The timeout value configured
for a local user has precedence over the value
configured for the captive portal instance.

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
