Linksys LAPAC1750PRO User Manual

110
Section 4: Maintenance of the Access PointLAPAC1750PRO Access Point Software User Manual
110
Section 4: Maintenance of the
Access Point
This section describes how to maintain the access point and see system detailed
information.
• Maintenance
• Diagnostics
Maintenance
From the access point Administrator UI, you can perform the following
maintenance tasks:
Firmware
• Switching Firmware Image
• Firmware Upgrade
Configuration Backup/Restore
• Backup Configuration
• Restoring Configuration
Reset/Reboot
• To Restore the Factory Default Configuration
• To Reboot the Access Point
Firmware
Use this page to select the firmware image that the AP loads when it boots and
to upload a new firmware image to the device.
Figure 63: Firmware Maintenance
Table 74: Firmware Information and Management
Field Description
Active Image Identifies the firmware images on the system:
• Active Image Firmware Version—The version number
of the image that is loaded during system boot.
• Inactive Image Firmware Version—The version
number of the inactive (backup) image on the system.
Upload Method The method to use to upload a new firmware image to the
AP:
• HTTP—Use a Web browser.
• TFTP—Use a TFTP server.
New Firmware
Image (HTTP
Upload)
Click Browse to find and select the new firmware image
located on an administrative system.
Image Filename
(TFTP Upload)
The path and filename of the firmware image to upload
to the AP.
Server IP (TFTP
Upload)
The IP address of the TFTP server where the new firmware
image is located.

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
