Section 3: Configuring the Access Point
LAPAC1750PRO Access Point Software User Manual
Rate The speed at which this access point is transferring data to
the specified client.
The data transmission rate is measured in megabits per
second (Mbps).
This value should fall within the range of the advertised
rate set for the mode in use on the access point. For
example, 6 to 54 Mbps for 802.11a.
Signal Indicates the strength of the radio frequency (RF) signal
the client receives from the access point.
The measure used for this is a value known as Received
Signal Strength Indication (RSSI), and will be a value
between 0 and 100.
RSSI is determined by a mechanism implemented on the
network interface card (NIC) of the client station.
Rx Total Indicates number of total packets received from the client
during the current session.
Tx Total Indicates number of total packets transmitted to the client
during this session.
Error Rate Indicates the percentage of time frames are dropped
during transmission on this access point.
Sorting Session Information
To sort the information shown in the tables by a particular indicator, click the
column label by which you want to order things. For example, if you want to
see the table rows ordered by signal strength, click the Signal column label.
The entries will be sorted by signal strength.
Channel Management
When Channel Management is enabled, the access point automatically
assigns radio channels used by clustered access points. The automatic
channel assignment reduces mutual interference (or interference with other
access points outside of its cluster) and maximizes Wi-Fi bandwidth to help
maintain the efficiency of communication over the wireless network.
You must start channel management to get automatic channel assignments;
it is disabled by default on a new AP.
At a specified interval, the Channel Manager maps APs to channel use and
measures interference levels in the cluster. If significant channel interference
is detected, the Channel Manager automatically re-assigns some or all of
the APs to new channels per an efficiency algorithm (or automated channel
plan). If the Channel Manager determines that a change is necessary, that
information is sent to all members of the cluster and a syslog message is
generated indicating the sender AP, new and old channel assignments.
The Channel Management page shows previous, current, and planned
channel assignments for clustered access points. By default, automatic
channel assignment is disabled. You can start channel management to
optimize channel usage across the cluster on a scheduled interval.
To configure and view the channel assignments for the cluster members, click
the Configuration > Cluster > Channel Management tab.

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
