Linksys LAPAC1750PRO User Manual

Section 2: Viewing Access Point System Status
LAPAC1750PRO Access Point Software User Manual
16
From Station The number of packets and bytes received from the
wireless client, and the number of packets and bytes
that were dropped after being received. Also, the
number of packets:
• in excess of an admitted TSPEC.
• for which no TSPEC has been established when
admission is required by the AP.
To Station The number of packets and bytes transmitted from
the AP to the client, and the number of packets and
bytes that were dropped upon transmission. Also, the
number of packets:
• in excess of an admitted TSPEC.
• for which no TSPEC has been established when
admission is required by the AP.
TSPEC Status and Statistics
The TSPEC Status and Statistics page provides:
• Summary information about TSPEC sessions by radio
• Summary information about TSPEC sessions by VAP
• Real-time transmit and receive statistics for the TSPEC VAPs on all radio
interfaces.
All transmit and receive statistics shown are totals since the AP was last started.
If you reboot the AP, these figures indicate transmit and receive totals since the
reboot.
To view TSPEC status and statistics, click the System Status > TSPEC Status
and Statistics tab. The following image has been edited to show some of the
transmit and receive statistics.
Figure 9: TSPEC Status and Statistics

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
