Linksys LAPAC1750PRO User Manual

Section 2: Viewing Access Point System Status
LAPAC1750PRO Access Point Software User Manual
12
Interface Statistics
The Interface Statistics page provides some basic information about the AP and
a real-time display of transmit and receive statistics for the Ethernet interface
on the AP, and for the VAPs on both radio interfaces. All transmit and receive
statistics shown are totals since the AP was last started. If you reboot the AP,
these figures indicate transmit and receive totals since the reboot.
To view transmit and receive statistics, click the System Status > Interface
Statistics tab.
Figure 5: Interface Statistics
Table 7: Interface Statistics
Field Description
Interface Status Table
Interface The name of the Ethernet or VAP interface.
Name (SSID) Wireless network name. Also known as the SSID,
this alphanumeric key uniquely identifies a
wireless local area network.
The SSID is set on the VAP tab. (See “Virtual
Access Point (VAP)” on page 43)
Status Shows whether the interface is enabled (up) or
disabled (down).
MAC Address MAC address for the specified interface.
The AP has a unique MAC address for each
interface. Each radio has a different MAC address
for each interface on each of its two radios.
VLAN ID Virtual LAN (VLAN) ID.
You can use VLANs to establish multiple internal
and guest networks on the same AP.
The VLAN ID is set on the VAP tab. (See “Virtual
Access Point (VAP)” on page 43)
Interface Statistics Table
Total Packets Indicates total packets sent or received by this
A P.
Total Bytes Indicates total bytes sent or received by this AP.
Dropped Packets Indicates total number of packets sent or
received by this AP that were dropped.
Dropped Bytes Indicates total number of bytes sent or received
by this AP that were dropped.
Errors Indicates total errors related to sending and
receiving data on this AP.
Click Refresh to refresh the information on the page.

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
