Linksys LAPAC1750PRO User Manual

23
Section 3: Configuring the Access Point
LAPAC1750PRO Access Point Software User Manual
Enabling or Disabling the Log Relay Host
on the Log Settings Page
To enable and configure Log Relaying on the Log Settings page, set the Log
Relay options as described in the following table, and then click Save.
Table 18: Log Relay Host
Field Description
Relay Log Select Enabled to allow the access point to send log messages
to a remote host. Select Disabled to keep all log messages on
the local system.
Relay Host Specify the IPv4 address, IPv6 address, or DNS name of the
remote log server.
Relay Port Specify the Port number for the syslog process on the Relay
Host.
The default port is 514.
NOTE:
To apply your changes, click Save. Changing some settings might cause
the AP to stop and restart system processes. If this happens, wireless
clients will temporarily lose connectivity. We recommend that you
change AP settings when WLAN traffic is low.
NOTE:
Hostnames are composed of series of labels joined with dots, as are
all domain names. Each label must be between 1 and 63 characters
long, and the entire hostname (including dots) has a maximum of 253
characters.
If you enabled the Log Relay Host, clicking Save will activate remote logging.
The AP will send its kernel messages in real-time for display to the remote log
server monitor, a specified kernel log file, or other storage, depending on how
you configured the Log Relay Host.
If you disabled the Log Relay Host, clicking Save will disable remote logging.
Email Alert
The Email Alert feature allows the AP to automatically send email messages
when an event at or above the configured severity level occurs. Use the Email
Alert page to configure mail server settings, to set the severity level that triggers
alerts, and to add up to three email addresses where urgent and non urgent
email alerts are sent.
Figure 17: Configuring Email Alert
Table 19: Email Alert Configuration
Field Description
Global Configuration
Admin Mode Globally enable or disable the Email Alert feature on
the AP. By default, email alerts are disabled.

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
