10
Front / Right Side View and Controls
Item Description
1 POWER LED
Illuminates red when the TV is in standby mode. The LED will illuminate blink red
confirming that a timer recording programme has started in the standby mode.
2 IR (Infrared Receiver)
Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
3
Press to select among different input signal sources:
DTV / ATV / AV / SCART / YPbPr / HDMI 1 / HDMI 2 / HDMI 3 / PC / USB.
Use the
buttons on the remote control to select the input, and then press the OK
button to confirm.
4 MENU Displays the OSD (on screen display) menu.
5 VOL (V) + / –
Adjusts the volume.
Press to select and adjust a setting in the OSD menu.
6 CH + / – Press to select a channel or select a sub-menu from the OSD menu.
7
Switches the TV on from standby mode.
Switches the TV back to standby mode.
1 2
CH
+
CH
–
V+V–
3 4 5 6 7
