LS tractor MT468 User Manual

3 -33
PTO gear lever
(3) Four wheel drive lever (4WD)
 This lever is used to engage/disengage the four
wheel drive (4WD). Pull it upward for engaging
the 4WD.
 Before operating the 4WD lever, press down the
clutch pedal and brake pedals, and stop the
tractor completely.
 4WD is very effective in the following cases.
- When increasing the towing power for heavy
work.
- In case of working in sandy soil.
- To prevent tractor from spinning in wet land.
Four wheel
drive lever
540rpm
Neutral
(2) PTO gear lever (optional)
 540 rev/min and neutral position is available.
 When attaching/detaching the rear implement,
placing the PTO gear lever to the neutral
position.
 Before operating the lever, depress the clutch
pedal and put PTO switch to the “OFF” position,
and stop the PTO shaft completely.
 For further information about the PTO shaft, see
chapter 4-5-(2) in this manual.
Notice
▶Operate the PTO gear lever by correct “I” pattern. If operated diagonally, it may
cause a failure. If the PTO gear lever is not engaged smoothly, shift the lever again
after lifting up the implement from the ground to align the drive shaft.
4WD
2WD
▶ When driving on public roads, disengage the 4WD. If not, it may cause damage of
the tires and transmission drive line and a serious accident. After working in the
field, disengage the 4WD before coming out from the field.
▶ While driving the tractor at high speed with the 4WD engaged, sharp steering may
cause a serious accident.
▶ Only operate four wheel drive lever by hand. If stepping on it , it may cause a
failure.
Caution
