6.
Air Conditioning
System
6-1. The name of each part of cooling and heating system
Heater
evaporator unit
Cooler
hose
Compressor
Heater hose
Condenser
w/receiver
drier
Quick cou
pler
▶
Maintenance of the air conditioning system and components (Comp
ressor,
Receiver
drier, Condenser, Heater
evaporator unit and connectio
n parts)
must be
perform
ed in a designated dealer. DO NOT disa
ssemble the compon
ents
arbitrary.
Caution
