5 -37
(3) Replacing Cabin air filters
Before servicing the filters, switch off the blower
and close all the cabin doors and windows.
Cabin air filters are installed on the left and right-
hand side under the cabin roof.
Unscrew the knobs under the roof and remove
the cover and filter elements as shown in the
right figure.
Clean both filter chambers with a damp, lint-free
cloth.
Replace the cabin air filters with a new one.
Re-install the filter covers and tighten the knobs.
▶ The filters are made of specially treated media with a rubber sealing strip bonded
around the sides. Take care not to damage the element during installation.
Notice
Cabin
air filters
Knobs
Filter
cover
