LS tractor MT468 User Manual

5 -31
5-9. Every 300 hour check
(1) Replacing Engine oil and Filter
▶ When engine oil is warm, the
impurities can be drained
completely.
Notice
① Drain Engine oil
 Run the engine for a few minutes to warm oil.
 Park the tractor on a level surface.
 Remove both LH and RH drain plugs of oil pan
and drain the oil completely.
Packing
Oil filling inlet
Drain plugs
(both side)
Close
Open
③ Fill Engine oil
 Tighten all the drain plugs. (Tightening torque :
40±5 N.m) (29.5±5 lbs-ft)
 Add new engine oil and check the oil level is
between MIN and MAX mark on the gauge.
 For oil specification, see chapter 5-3, “Lubricants
and Capacity” or the last page in this manual.
 Check any leakage of the engine while running
the engine for several minutes at idle rpm.
 Stop the engine. After about 5~10 minutes later,
check again if the oil level is between MIN and
MAX marks. Install the oil gauge.
② Replace Engine oil filter
 Clean carefully around the filter.
 Coat clean engine oil on the packing of new filter
and check the packing is placed well in the
groove.
 Turn the oil filter counter-clockwise to remove it
with a filter wrench.
 Turn the new filter clockwise to assemble it until
the packing makes contact with the mounting
surface. Tighten ¾ to 1 turn more after packing
contact.
 If the metal is attached to the element of oil filter
to be disassembled, contact your authorized
local dealer.
Engine oil filter
Engine oil gauge
