4
-1
4
(3) 7-Pole
connector (option
al)
One
of the standard
7-pole trailer
connectors is provid
ed and
i
s mounted
at the
rear of the
tractor.
The connections of the 7-pole connector (viewed from the
rear o
f the
tractor)
are as
follows;
ASAE V
ersion
Pin No.
Function
1
Gr
ound (Earth)
2
Working
light
3
Left turn signal
light
4
Brake
light
5
Right turn signa
l light
6
License
number
plate
light
7
Auxiliary
7-Pole Connecto
r (ASAE)
135
