5 -18
(2) Hydraulic oil pressure
Indicator (optional)
When this indicator turns on, the PTO shaft will
be stopped automatically to protect the PTO
clutch.
At this time, push the PTO switch to the OFF
position, and turn it ON again to restart the PTO.
If the PTO system pressure is normal, the PTO
will rotate continuously. if not, the PTO shaft will
be stopped again after 5~6 seconds later.
In this case, you must contact your authorized
dealer to check the hydraulic PTO system.
(3) Engine oil pressure indicator
This indicator① will be turned on when turning
the key switch from “OFF” to “ON” position. After
starting engine, this indicator must be turned off.
If this indicator turns on while the engine is
running, STOP THE ENGINE IMMEDIATELY.
Check the engine oil level first, and if necessary,
add new engine oil and recheck the indicator.
If the engine oil level is normal, it means that
there is a problem on the lubrication system,
contact your authorized local dealer for check.
(4) Battery charging indicator
This indicator② will be turned on when turning
the key switch from “OFF” to “ON” position. After
starting engine, this indicator must be turned off.
If this indicator turns on while engine is running,
it means that there is a problem on the electric
charging system.
If the problem is not cleared, stop the engine and
contact your authorized local dealer for check.
ON : PUSH AND TURN
OFF : PUSH
Hydraulic oil
pressure indicator
PTO
switch
12
To Next Page
