3. Instruments and Controls
3-1. Instrument
panel and Front controls
Clutch ped
al
Light
switch
Turn signal
light switch
Hazard
warn
ing
light indicato
r
Horn switch
(optional)
Grille work
light switch
Shuttle
lever
Throttle
lever
Key
switch
PTO switch
Tilt lever
(See pag
e
2-7)
Brake pedals
Throttle
pedal
Instrument
panel
Important to owner
, read carefully
PTO mode
s
witch
(optional)
DPF switch
Beacon
lamp switch
(cabin
models only)
Dep
ending on
the optional specifications, some figures
may be d
ifferent
from your
tractor.
