90-830234R3
DECEMBER 1997
ELECTRICAL
- 2D-21
T
achometer (With Adjustable Dial) and
T
rim Indicator Gauge Wiring Diagram
a
b
c
d
e
BA
TT
GND
SENDER
BLK
=
BLACK
BLU
=
BLUE
BRN
=
BROWN
GR
Y
=
GRA
Y
GRN
=
GREEN
PUR
=
PURPLE
RED
=
RED
TA
N
=
TA
N
VIO
=
VIOLET
WHT
=
WHITE
YEL
=
YELLOW
a
-
T
achometer
b
-
Position Dial to Point T
oward “4”
c
-
T
rim Indicator Gauge (Optional)
d
-
T
achometer/Accessories Harness Plug from
Remote Control
e
-
T
achometer/Accessories Harness
140
142
