4-66 - POWERHEAD
90-830234R3
DECEMBER 1997
1994 and Newer 3 Cylinder Harness Routing (with Oil
Reservoir Installed)
a
b
c
d
e
f
g
54162
a
-
T
rigger Harness
b
-
V
oltage Regulator Harness
c
-
NEGA
TIVE (–) Battery Cable
d
-
Low Oil W
arning Module Harness
e
-
POSITIVE (+) Battery Cable
f
-
Power Trim Harness
g
-
Lower Cowl Power T
rim Harness
277
279
