Mindray DC-26 User Manual

11-2 Troubleshooting of Regular Malfunctions
up normally
3
The AC input is normal ,AC power
indicator remains off;
Power indicators: off
AC-DC power
board fails
Replace power
module
4
AC power indicator: ON;
Power–on status indicator: off after
power button pressed
Power indicators: off
AC_DC power
board: function
normal;
DC-DC power
board: fails
Replace power
module
5
AC power indicator: ON;
Power–on status indicator: blinks after
power button pressed
Power indicators: off
CPU module: fails
Replace CPU
module
6
AC power indicator: ON;
Power on/off indicator: blinks and turns
on after pressing power button
Power indicator: 5V off or 3.3V off
DC-DC power
board: fails
Replace power
module
11.2 System Cannot Start up Normally
11.2.1 Module or Board Related
No.
Descriptions
Remarks
1
CPU module
2
HDD
11.2.2 Key Points Supporting Troubleshooting
No.
Key Points Supporting Troubleshooting
Remarks
1
Character and progress status during the
starting of the system
2
Alarm and prompts during the starting of the
system
3
Backlight status during power on the control
panel
Support to check if the
malfunction occurs in power
supply module or CPU module
