Mitsubishi Electric A173UHCPU Programming Manual

7. POSITIONING CONTROL
7 − 19
7.2 1-Axis Linear Positioning Control
Positioning control of the designated axis from the current stop position to a fixed
position.
Positioning control uses ABS-1 (absolute data method) and INC-1 (incremental
method) servo instructions.
Items Set by Peripherals
Common Arc Parameter Block Others
Servo
Instruction
Positioning
Method
Number of
Controllable
Axes
Parameter Block No. Axis Address/Travel Value Commanded Speed Dwell Time M-Code Torque Limit Value Auxiliary Point Radius Center Point Control Unit Speed Limit Value Acceleration Time Deceleration Time Rapid Stop Deceleration Time Torque Limit Value Deceleration Processing on Stop Input Allowable Error Range for Circular Interpolation S-Curve Ratio Cancel Start Speed Change
ABS-1
Absolute data
INC-1
Incremental
1 ∆ !!! ∆∆ ∆∆∆∆∆∆ ∆∆∆OK
! : Must be set
∆ : Set if required
[Control Details]
Control with ABS-1 (absolute data method)
(1) Positioning control from the current stop address (pre-positioning address) to
the designated address, using the home position as the reference.
(2) The travel direction is determined from the current stop address and the
designated address.
The travel direction is shown below if the current stop address is 1000, and the
designated address is 8000.
Current stop address
Designated address
Positioning control
Home position
1000
0
8000
Fig.7.1 Positioning by Absolute Data Method
Example
