4. PARAMETERS FOR POSITIONING CONTROL
4 − 2
4.2 Fixed Parameters
(1) The fixed parameters are set for each axis and their data is fixed in accordance
with the mechanical system or other factors.
(2) The fixed parameters are set with a peripheral device.
(3) The fixed parameters to be set are shown in Table 4.1.
Table 4.1 Fixed Parameters
Setting Range Default
mm inch degree PULSE
No. Item
Setting
Range
Units
Setting
Range
Units
Setting
Range
Units
Setting
Range
Units
Initial Value Units
Remarks
Expla-
natory
Section
1 Unit setting 0  1  2  3  3 
• Set the command unit in
positioning control for each
axis.

2
Number of
pulses per
revolution
(AP)
1 to 65535 PLS 20000 PLS
• Set the number of feedback
pulses per motor revolution,
which is determined by the
mechanical system.
3
Travel
value per
revolution
(AL)
0.1 to 6553.5 µ m
0.00001 to
0.65535
inch
0.00001
to
0.65535
degree 1 to 65535 PLS 20000 PLS
• Set the travel value per
motor revolution, which is
determined by the
mechanical system.
4
Travel value per pulse (A)
Unit
magnifica-
tion (AM)
1: ×1, 10: ×10, 100: ×100, 1000: ×1000 
• Set to change the
magnification for the travel
value per pulse.
4.2.1
5
Backlash
compensation
amount
(Note)
0 to 6553.5 µ m 0 to 0.65535 inch
0 to
0.65535
degree 0 to 65535 PLS 0 PLS
• Set the amount of backlash
in the machine.
• Every time the positioning
direction changes during
positioning, compensation
by the backlash
compensation amount is
executed. The expression
below shows the setting
range.
0 ≤ (backlash
compensation amount) ×
AP/AL ! AM ≤ 65535
8.3
6
Upper stroke
limit (Note)
−214748364.8
to
214748364.7
µ m
−21474.83648
to
21474.83647
inch
0 to
359.99999
degree
−2147483648
to
2147483647
PLS 2147483647 PLS
• Set the upper limit for the
machine travel value. The
expression below shows
the setting range.
(SV13 only) −2147483648
≤ (upper stroke limit) ×
AP/AL ! AM ≤ 2147483647
7
Lower stroke
limit (Note)
−214748364.8
to
214748364.7
µ m
−21474.83648
to
21474.83647
inch
0 to
359.99999
degree
−2147483648
to
2147483647
PLS 0 PLS
• Set the lower limit for the
machine travel value. The
expression below shows
the setting range.
(SV13 only) −2147483648
≤ (lower stroke limit) ×
AP/AL ! AM ≤ 2147483647
4.2.2
8
Command
in-position
range (Note)
0.1 to
214748364.7
µ m
0.00001 to
21474.83647
inch
0.00001
to
359.99999
degree
1 to
2147483647
PLS 100 PLS
• Set the position at which
the command in-position
signal (M1603 +
20n/Xn3/M2403 + 20n) is
turned ON [(positioning
address) − (current value)].
The expression below
shows the setting range.
1 ≤ (command in-position
range) × AP/AL ! AM ≤
32767
4.2.3
9
Limit switch
output
used/not used
0: Not used
1: used
0 
• Set whether the limit switch
output function is used or
not for each axis.
8.1
(Note) :The display of the possible setting range differs according to the electronic gear value.
