5Maintenance and Inspection
Maintenance parts 5-111
5.4 Maintenance parts
The consumable parts that must be replaced periodically are shown in Table 5-4, and spare parts that may be
required during repairs are shown in Table 5-5. Purchase these parts from the dealer when required. Some
Mitsubishi-designated parts differ from the maker's standard parts. Thus, confirm the part name, robot arm and
controller serial No. and purchase the parts from the dealer.
Table 5-4 ： Controller consumable parts list
Table 5-5 ： Controller spare parts list
No. Part name
Type
Note1)
Note1) Confirm the robot arm serial No., and contact the dealer or service branch of Mitsubishi Electric Co., for
the type.
Qty. Usage section Maker
1 Lithium battery Q6BAT 1 CR750/CR760 controller:
Inside the interface cover on the
front of the controller.
Mitsubishi Electric
System & Service;Co.,Ltd.
CR751 controller:
Inside the filter cover
2 Filter BKOFA0773H42 1 CR750 controller:
Inside the filter cover.
BKOFA0773H41 1 CR751 controller:
Inside the filter cover.
No. Part name
Type
Note1)
Note1) Confirm the robot arm serial No., and contact the dealer or service branch of Mitsubishi Electric Co., for
the type.
Qty. Usage section Maker
11.6A fuse LM16 1
Mitsubishi Electric
System & Service;Co.,Ltd.
23.2A fuse HM32 1
34A fuse LM40 1
43.2A fuse LM32 1
5 7.5A fuse GP75 1
