2-6 Confirming the products
2Unpacking to installation
2 Unpacking to installation
2.1 Confirming the products
Confirm that the parts shown in the standard configuration of the controller shown in Table 2-1 are enclosed
with the purchased product.
Users who have purchased options should refer to the separate "Standard Specifications". The primary power
supply cable and grounding cable must be prepared by the customer.
Table 2-1 ： Standard configuration
No. Part name Type Qty. Remarks
CR750-D controller
1 Controller CR750-D 1 unit Stand alone type
2 Safety manual BFP-A8006 1 copy
3 CD-ROM (Instruction manual) 5F-FA01-C00 1 pc. Stand alone type
4 Dummy plug for T/B 2D-DP1 1 pc. Connect, when not using T/B.
5 CNUSR connector (Connector cover) 10350-52Y0-008 1 pc.
6 CNUSR connector (Plug) 10150-3000 PE 1 pc.
7 CNUSR connector BU770D007G51 3 pcs. For the CNUSR11/12/13 connector.
8 Ferrite core E04SR301334 1 pc. For emergency stop wiring
9 Noise filter SUP-EL20-ER6 1 pc. CE specification only.
10 Lock cover set HL-05FA 1 pc. For locking the power switch.
11 1.6A fuse (reserves) LM16 2 pcs.
12 3.2A fuse (reserves) HM32 2 pcs.
13 4A fuse (reserves) LM40 1 pc.
14 3.2A fuse (reserves)
LM32
1 pc. Only with a controller for the following models.
RV-13F/13FL/20F series, RH-1FHR
15 Guarantee Card 1 copy
CR751-D controller
1 Controller CR751-D 1 unit Stand alone type
2 Safety manual BFP-A8006 1 copy
3 CD-ROM (Instruction manual) 5F-FA01-C00 1 pc. Stand alone type
4
ACIN connector
Note1)
1-179958-3
1 pc.
5
ACIN terminal
Note1)
316041-2
2 pcs. Only with single-phase controller
3 pcs. Only with three-phase controller
6 Power cable (with the ACIN connector)
Note1)
BU774D126G03 1 pc. Only with single-phase controller. Length: 3m
BU774D126G23 1 pc. Only with three-phase controller. Length: 3m
7 Dummy plug for T/B 2F-DP1 1 pc. Connect, when not using T/B.
8 CNUSR connector (Connector cover) 10350-52Y0-008 2 pcs.
9 CNUSR connector (Plug) 10150-3000 PE 2 pcs.
10 Ferrite core E04SR301334 1 pc. For emergency stop wiring
11 1.6A fuse (reserves) LM16 2 pcs.
12 3.2A fuse (reserves) HM32 2 pcs.
13 4A fuse (reserves) LM40 1 pc.
14 3.2A fuse (reserves)
LM32
1 pc. Only with a controller for the following models.
RV-13F/13FL/20F series, RH-1FHR
15 Cover plate BU773C012G61 1 pc. For connector protection of the controller.
16 Cable fixing plate BU773C011H02 1 pc. For fixing the cable of the controller.
17 Cable clamp
AB-10N
1 pc. For fixing the machine cable (CN1)
One fixing screw (M4) is attached.
AB-6N
4 pcs. For fixing TB cable, power supply and FG cable,
communication cable and machine cable (CN2)
Four fixing screws (M4) are attached.
18 Guarantee Card 1 copy
