5 - 47
*1: 136 is set by default (This value depends on the parameter setting).
*2: After the decimal point of a value found by the number of bit device points/16 is rounded up.
For calculation example of memory capacity, refer to Section 5.4.4.
Table5.12 Calculation of file size (High Performance model QCPU, Process CPU, and Redundant CPU) (continued)
Function Rough file capacity (unit: Byte)
Local device
72 + 6 (set device type) + (2 ((total number of M and V points)/16 + (number of D points)
+ 18 (total number of T, ST, and C points)/16)) (number of programs)
• M, V, D, T, ST, and C indicate the following set devices.
M: internal relay
V: edge relay
D: data register
T: timer
ST: retentive timer
C: counter
