CHAPTER9 DEVICES
This chapter describes the devices that can be used in the CPU module.
9.1 Device List
Table9.1 and Table9.2 list the names and data ranges of the devices that can be used in the CPU module.
(1) Basic model QCPU
(To the next page)
Table9.1 Device list
Classification Type Device name
Default
Parameter-
set range
Reference
Points Range
Internal user device
Bit device
Input 2048 X0 to 7FF Hexadecimal
Can be changed
within 16.4K
words
*3
Section 9.2.1
Output 2048 Y0 to 7FF Hexadecimal Section 9.2.2
Internal relay 8192 M0 to 8191 Decimal Section 9.2.3
Latch relay 2048 L0 to 2047 Decimal Section 9.2.4
Annunciator 1024 F0 to 1023 Decimal Section 9.2.5
Edge relay 1024 V0 to 1023 Decimal Section 9.2.6
Step relay 2048 S0 to 127/block Decimal Section 9.2.9
Link relay 2048 B0 to 7FF Hexadecimal Section 9.2.7
Link special relay 1024 SB0 to 3FF Hexadecimal Section 9.2.8
Word device
Timer
*1
512 T0 to 511 Decimal
Section 9.2.10
Retentive timer
*1
0 (ST0 to 511) Decimal
Counter
*1
512 C0 to 511 Decimal Section 9.2.11
Data register 11136 D0 to 11135 Decimal Section 9.2.12
Link register 2048 W0 to 7FF Hexadecimal Section 9.2.13
Link special register 1024 SW0 to 3FF Hexadecimal Section 9.2.14
Internal system
device
Bit device
Function input 16 FX0 to F Hexadecimal
Cannot be
changed
Section 9.3.1
Function output 16 FY0 to F Decimal Section 9.3.1
Special relay 1024 SM0 to 1023 Decimal Section 9.3.2
Word device
Function register 5 FD0 to 4 Decimal Section 9.3.1
Special register 1024 SD0 to 1023 Decimal Section 9.3.3
Link direct device
Bit device
Link input 8192 Jn\X0 to 1FFF Hexadecimal
Section 9.4
Link output 8192 Jn\Y0 to 1FFF Hexadecimal
Link relay 16384 Jn\B0 to 3FFF Hexadecimal
Link special relay 512 Jn\SB0 to 1FF Hexadecimal
Word device
Link register 16384 Jn\W0 to 3FFF Hexadecimal
Link special register 512 Jn\SW0 to 1FF Decimal
Module access
device
Word device
Intelligent function
module device
65536
Un\G0 to 65535
*2
Decimal Section 9.5
Index register Word device Index register 10 Z0 to 9 Decimal Section 9.6
File register
*5
Word device File register 64k
• R0 to 32767
• ZR0 to 65535
Decimal Section 9.7
Nesting - Nesting 15 N0 to 14 Decimal Section 9.8
