27
Connections
ENGLISH
Optional products
DX-ZD6UE
DX-ZD5UE(Z)
Additional hard disk unit (for serial bus connection)
By connecting various external HDDs to this unit, you
can expand the memory or use them as a copy device.
However, when you perform recording, playback, or copy
at a high rate using this unit, recording or playback data
dropout or other failure may occur depending on the
connected device because of slow data transfer or slow
response. Be sure to check for such failure before starting
the practical operation of the recorder.
Don't use the function to control the powers of external
devices using the bus power of this recorder.
When using DX-ZD6UE, you can use the mirroring and
spanning functions.
DX-RM5(ZD)
Rack-mount adapter for additional hard disk unit DX-
ZD6UE/DX-ZD5UE(Z)
DX-KB5UE
Keyboard for digital recorder
DX-RM3
Rack-mount adapter for digital recorder DX-TL308E/DX-
TL304E series
Recommended products
For recommended external devices, contact your dealer.
External devices you want to use may not be suitable for
the intended application of this recorder. For details, you are
recommended to contact your dealer.
By connecting various external HDDs to this recorder, you
can expand the memory or use them as a copy device.
However, when you perform recording, playback, or copy
at a high rate using this unit, recording or playback data
dropout or other failure may occur depending on the
connected device because of slow data transfer or slow
response. Be sure to check for such failure before starting
the practical operation of the recorder.
Caution for connecting additional hard disk units
When you connect 5 or more additional hard disk units to this recorder, you are recommended to connect them by USB
cables as shown below in order to prevent recognition failure caused by variation in their startup time.
At the commencement of practical operation, check that they are recognized correctly even when a small number of units are
connected.
Recorder
Additional
unit
Additional
unit
Additional
unit
Additional
unit
IN
OUT
IN
IN
OUT
IN
Additional
unit
OUT
IN
Additional
unit
OUT
IN
Additional
unit
OUT
IN
Additional
unit
OUT
IN
Notice
• When you play back data stored in the extension unit during recording to the same extension unit at a rate close to
the recorder’s maximum processing capacity (for example of DX-TL308E, at 12.5 FPS for all the cameras in the 2CIF
picture size), noise may appear in the image or audio. In addition, when you make backups of the data to the extension
unit during recording on the recorder, make sure to set the total recording rate of cameras to half or less of the upper
limit of the designated picture size (4CIF, 2CIF, or CIF).
To Next Page
