Mitsubishi MELDAS HS Series User Manual

Chapter 2 Specifications
2–4
2-3 Outline dimension drawings
2-3-1 HS-MF23
45°
φ 70
Φ11h6
4
4
2.5
A
Cross-section
A-A
16
30
4
3
7
178
108
18
82
Φ50h7
56.5
101
Φ27
60
±5
640±30
A
A
With oil seal
2-3-2 HS-RF43/73
Connector
JL04V-2A28-11PE
LL
93
□ 100
25
φ16.000
φ22
28
12
Taper
1/10
18
φ95h7
10
5
0
-0.03
54.3
φ
115
4- φ 9
45 ﾟ
L
75
173.5
φ
135
118
23.3
100
3
A
108.00
A
A
Cross-section
A-A
With oil seal
Changed dimensions
Model L LL
HS-RF43 400W 86 204
HS-RF43B 400W with brakes In planning stages
HS-RF73 750W 104 222
HS-RF73B 750W with brakes In planning stages
