Mitsubishi MELDAS HS Series User Manual

Chapter 6 Wiring
6–3
6-1 System connection diagram
サーボ
MDS-
B-
V1,V2
主軸
MDS-
B-SP
バッテリーユニット
A-BT
ﾊﾟﾜｰｻ
ﾌﾟﾗｲ
MDS-
B-CV
DC24V
ＭＣ
ＮＦ
ＭＣ用リレー
制御回路電源用AC200V
L11,L12
ブレーキ回路
B-AL
ACリア
クトル
MELDASCNC
インテリジェント
サーボモータ
主回路電源用
3φAC200VL1,L2,L3,
I/Fユニット HS-IF-6
Note)
1) Keep the cable length to within 30m.
2) This is a motor with magnetic brakes. The power connected to the magnetic brake does not
have a polarity.
3) Securely connect the shield wire to the plate (grounding plate) in the connector.
4) When using as an absolute connector, connect MDS-A-BTo.
AC
reactor
Intelligent servomotor
200VAC L11, L12 for
control circuit power
MC relay
Battery unit
A-BT
Power
supply
MDS-
B-CV
Spindle
MDS-
B-SP
Servo
MDS-
B-
24VDC
Brake circuit
I/F unit HS-IF-6
3ø200VAC L1, L2,
L3 for main circuit
power
